Our fold-back type servo electric cylinder is also known as parallel mount servo linear actuator. Different from inline electric cylinders, the servo motor is installed in parallel beside the cylinder body, which effectively shortens the overall length. It is the ideal solution for equipment with limited installation space.
Multiple standard models are available on this page. Customers can select different models, rated thrust and stroke via the variant options. Custom mounting, IP grade and accessories are supported. Download datasheet or send your technical parameters for quotation if you cannot find your required specs.
Key Advantages
1.Compact Fold-back Structure
Parallel motor layout greatly reduces total length, saves mounting space for narrow installation scenarios.
2.High Precision Ball Screw Transmission
Adopts high-performance ball screw, features low backlash, high repeat positioning accuracy and stable operation.
3.Wide Range of Thrust & Stroke Options
Various standard models for selection; stroke and thrust can be customized according to your working requirements.
4. Strong Load Capacity & Stable Performance
Suitable for continuous reciprocating operation, low noise and long service life.
5.Flexible Mounting & Customization
Multiple mounting flanges and connection ends optional. OEM & ODM service available.
6.Good Protection Grade
Optional IP65 protection, works steadily in harsh industrial workshop environments.
Application Scenarios
Fold-back servo electric cylinders are widely used in industries requiring compact linear motion:
✅ Servo press & assembly equipment
✅ Fatigue testing machines and material test benches
✅ Motion simulation platforms
✅ Automated production lines, clamping & positioning mechanism
✅ Packaging machinery, logistics sorting equipment
✅ Other automation equipment with limited installation space
Package & Delivery
Standard package: Plywood case or carton with foam protection
Delivery time: Based on selected model and order quantity
Attached documents: Datasheet, wiring diagram and operation manual (PDF)
How to Order & Inquiry
1. Select your target model, rated thrust and stroke from the variant options on this page
2. Check mounting dimension and confirm whether you need customized accessories
3. If no matching specs, please send us your requirements: thrust, stroke, mounting size, working speed and quantity
4. We will provide technical drawing, datasheet and formal quotation for your review
FAQ
Q: Can I customize the fold-back servo electric cylinder?
A: Yes. Custom stroke, flange, connection thread, cable length and IP grade are acceptable. Please send your technical requirements.
Q: What is the difference between fold-back type and inline electric cylinder?
A: Fold-back type features parallel motor design with shorter overall length for limited space; inline type has motor in line with cylinder with simpler structure.
Thông tin bổ sung
Series
QDA40, QDA53, QDA60, QDA75, QDA80, QDA97
Stroke
Up to 500 mm, Up to 1200 mm, Up to 1500 mm, 100–2000 mm
Mounting
Direct, Indirect, Reinforced Base, Front Flange, Horizontal, Guide / Rod Eye / Joint, Gearbox configurations
Motor Brand
Mitsubishi, Yaskawa, Delta, Panasonic, Other
Motor Output
50W, 100W, 200W, 400W, 750W, 1000W, 1500W
Screw / Lead
0802 (QDA40), 1210 (QDA53), 1605 / 1610 (QDA60), 2005 / 2010 / 2505 / 2510 (QDA75), 25 mm screw · 05 / 10 mm lead (QDA80), 25 mm screw · 05 / 10 mm lead (QDA97)
Sensor
CS1-M Reed Switch.1m, CS1-MP PNP .3 m, CS1-MN NPN .3 m, Custom sensor configuration
